Specifications:

♦ Machine Structure:
- Whole machine structure made by stainless steel parts and 6061 T6 aluminum alloy with anodizing treatment, rust free.
♦ Machine Specification:
- Labeling Precision: ± 0.3 ~ 0.5mm
- On the basis of flat surface
- Excluded tolerance of substance or mold).
- Machine Speed: Approx. 36 M/Min.
- Operation Speed: Approx. 3 ~ 6 M/Min.
- Operation Capacity: Approx. 30 PCS/Min.
- Label Size: Max. 170 x 136 MM (base paper 140 MM wide)
- Guard Door can be optional to be equipped.

Features:

♦ Control System:
• Twin-Axis Servo Motor Control Precision Labeling System.
• Operation Control System:
   Inter-Faced HMI Colorful Touch Screen Monitor ("PROFACE").
• Programmable Logic Control System: "MITSHBISHI" PLC.

* The brand names of products shown in the catalogue are the reference application to  our manufacturing equipment only.

Order Information:

• Minimum Order: Negotiable
• Branded Product
