Specifications:

￭ Machine Specification:
￭ Range of finished bag:
   150~450 (W) x 240~500 (L) x 80~120 (H) mm, 1-Layer ​
   Ex. 400 (L) x 500 (W) x 110 (H) mm x 1-layer
￭ Designed / Operation Speed:
  15 / 5 ~ 10 bags/min depend on products & arraying configuration
￭ Bag material:
- Pre-formed polyethylene bags
- Film thickness 25 ~ 30 micron
￭ Wrapping Range:
   Depends on product specification, wrapping size and product array

Features:

￭ OPERATION CONTROL:
• Fully Automatic Feeding, Packing & Collecting
• Programmable Logic Control (PLC) System
• HMI Inter-faced Touch Screen Monitor Control
• Mechanic Cam with Servo Motor Control System

￭ MODE OF OPERATION:
• Strong iron frame structure
• Automatic arraying & feeding system.
• Automatic output delivery system.
• The bag is sealed, trimmed automatically.
• The sealed bag moved out of the station automatically.
• The product is conveyed into opened bag automatically.
- By overhead chain with pusher arms into opened bag.
• The bag is opened by suction arms and spreader plates
• Tissue will be inserted into the bag automatically
• Pusher arm loads the opened bag with the products
• It will transfer the filled bag to sealing station.
• Accurate cam driving system
• Controlled by servo system to insure machine movement smoothly.
• Touch screen monitor convenient operation and faster setting:
- For changing product formats.

◊ Optional Distributor
◊ Optional 2-Layer Up/Down System
◊ Horizontal or Vertical Feeding to be selected

￭ CONFIGURATION:
The above-mentioned possible configurations are for reference only. The final specification of machine will depend on the specification of single wrapped bags and the way of arraying configuration.

Order Information:

• Minimum Order: Negotiable
• Branded Product
