321-VA-EGAA-S4BC Automatic Thermoforming Egg Carton/Box/Clamshell Labeling Machine

Thermoforming Egg Carton/Box/Clamshell Labeling Machinel

Product ID: Plastic Thermoforming Egg Carton/Box/Tray/Clamshell Labeling 321-VA-EGAA-S4BC Series (153)

￭ Model: 321-VA-EGAA-S4BC
♦ Pressure Sensitive Self-adhesive Type of Label
♦ Twin-Head Labeling System
♦ For Plastic Vacuum /Thermoforming Egg Carton/Tray/Clamshell
♦ Automatic Continuous Supplementary Feeding
♦ No Need to Stop the Machine For Re-filling
♦ Automatic Pre-Set Quantitative Separation
♦ Batched Quantity Automatic Collecting System

￭ Product Example:
- 6-Cell Egg Carton/Box/Tray
- 10-Cell Egg Carton/Box/Tray
- 12-Cell Egg Carton/Box/Tray
- 15-Cell Egg Carton/Box/Tray
- 2 * 6-Cell Egg Carton/Box/Tray
- 30-Cell Egg Tray Lid
- Clamshell
- Food Container
- Fruit Box

Specifications:

￭ Specification:
• Labeling Speed: Approx.40 pieces/min
• Reference Labeling Product:
• Lay-Flat 145 ~ 150 (L)*220 (W) mm
• Main Label: Max. 200 (L)*160(H) MM Included Base Paper
• Strip Label: Max. 200 (L)*13(H) MM Included Base Paper
• Label Roll: Ø 300 (O.D.)*76 (I.D.) mm
• Machine Size: Approx.5000 (L)*900 (W)*1450 (H) mm

Model 311-VA-EGAA-S3BC for single main label type is also available.

Features:

￭ Control System:
• Japan "MITSUBISH" PLC Control System.
• Japan "YASKAWA" Servo Motor Control System.
• Interfaced 10" Colorful HMI Touch Screen Monitor.
• Label Sensor: "SICK" Optoelectronic Sensor.
• Product Detect Sensor: "OMRON" Optoelectronic Sensor.

Order Information:

Minimum Order: Negotiable
Branded Product
