Specifications:

￭ Specification:
￭ Operation Speed
Model 841-VP:
Approx. 1.3 ~ 1.6 PCS/Sec * 1-Lane (Approx. 78~96 PCS/MIN)
Model 842-VP:
Approx. 1.3 ~ 1.6 PCS/Sec * 2-Lane (Approx. 156~192 PCS/MIN)
Model 843-VP:
Approx. 1.3 ~ 1.6 PCS/Sec * 3-Lane (Approx. 234~288 PCS/MIN)
♦ Equipped with Automatic Peel-off & Taking System.
​♦ Equipped with Servo Control 3-Jaw Roller Cutting System.
♦ Equipped with "NORDSON" Hot-Melt Glue Applicator.​
♦ Equipped with High Speed Sticking-Padding System.
• Product Size: Max. 180 ~ 200 (L) * 100~130 (W) * 30~50 (H) mm.
• Pad Size: Max. 160 ~80 (L) * 120~80 (W) mm.
• Pad Roll: ø 600 (O.D.) * 76 (I.D.) mm.
• Machine Size:
- Model 841-VP: Approx. 8000*700*2000 MM
- Model 842-VP: Approx. 8000*900*2000 MM
- Model 843-VP: Approx. 8000*1100*2000 MM

Features:

￭ Features:
♦  Operation: Automatic Peel-off, Feeding, Padding, Collecting
• Japan "MITSUBISH" PLC Control System.
• Japan "YASKAWA" Servo Motor Control System.
• Interfaced 10" Colorful HMI Touch Screen Monitor.
• Padding Sensor: Japan "KEYENCE" Optoelectronic Fiber Sensor.
• Product Detect Sensor: "OMRON" Optoelectronic Sensor.

* The brand names of products shown in the catalogue are the reference application to our manufacturing equipment only.

Order Information:

• Minimum Order: Negotiable
• Branded Product
