Specifications:

￭ Specification:
- Automatic Bag Suction Taking System
- Automatic Up-Down Feeding System
- Static Electricity Eliminating System
- Mark integrating & manage System
- Miss Label Detection System
- Automatic Stacking Collecting System
• Intermittent Movement Collecting Conveyor
• Automatic Labeled Bags Stack Collecting System
• Labeling Accuracy: ± 2 mm
   (on the basis of flat surface as standard)
• Labeling Accuracy: 15 ~ 20 PCS/MIN
• Labeling Height and Forward/Backward Position Adjustable

Features:

￭ Features & Advantages:
• Servo Motor Control Labeling System with Servo Control Conveyor
• Labeling Height and Forward/Backward Position Adjustable
♦ Main machine structure:
• Whole machine structure made by stainless steel and 6061 T6
   aluminum alloy with anodizing treatment and rust free.
• Conveyor: 1,200 mm (L) x 250 mm (W) x 750 mm (H)
• Included X-Axis Labeling-Head Angle Adjustment System
• Label Size: Max. 120 mm (L) x 120 mm (H)
• Label Roll: Included Base Paper: ∮300 O.D. & ∮76 mm I.D.
• With high precision sensor detect and activating system.
• With servo motor control labeling system.

♦ Control System:
＊ Japan “MITSUBISHI” PLC Control System
＊ Servo Motor Control Labeling System: Japan “YASKAWA ”
＊ Conveyor : Japan “YASKAWA" Servo Motor  with Italy Reducer
＊ Interfaced Colorful Touch Screen Monitor (HMI)
＊ Label Detect Sensor: Japan "KEYENCE” Sensor
＊ Optoelectronic Fiber Sensor: Included Focusing Lenses
＊ Product Detect Sensor: Japan “KEYENCE” Optoelectronic Fiber Sensor

* The brand names of products shown in the catalogue are the reference application to our manufacturing equipment only.

Order Information:

• Minimum Order: Negotiable
• Branded Product
