Specifications:

￭ Specification:
• Pressure Sensitive Self-Adhesive Label.
♦ Machine speed:
- 310-V3H: Approx. 80 ~ 90 pcs/min
- 310-V6H: Approx. 100 pcs/min
• Servo Control Conveyor: 2400*200*1000 MM / 5000 * 200 *850 MM
♦ Servo Control Conveyor Equipped with Mold-Sets:
- 310-V3H: 30 Sets
- 310-V6H: 66 Sets
• Lid to be Stacked in Stack-Hopper
• 310-V3H: 3-in-1 Stacked-Hopper Magazine
• 310-V6H: (3-in-1) * 2 Stacked-Hopper Magazine
• Automatic Position Setting System
• 310-V6H:
- Equipped with NG Product Taking-Collecting System
- Equipped with CCD Detect & Monitoring System
- Equipped with Aluminum Safety Protection Door & Frame

• Machine Dimension:
Approx. 2,700 (L)*750 (W)*1,600 (H) mm / 5,500 * 800 * 1780 MM

Features:

￭ Features & Advantages:
• Lid to be Stacked in Stack-Hopper Magazine.
• Lid to be taken from Bottom of Hopper Automatically.
• High Accuracy Servo Control Labeling System.
• Precise Labeling with Enhanced Pressure Labeling System.
• Labeled Lids Automatic Stack for Collecting.
• Batched Labeled Lids Automatic Move-Out for Collecting.

♦ Control System:
＊ Japan “MITSUBISHI” PLC Control System
＊ Servo Motor Control Labeling System: Japan “YASKAWA ”
＊ Conveyor : Japan “YASKAWA" Servo Motor  with Italy Reducer
＊ Interfaced Colorful Touch Screen Monitor (HMI)
＊ Label Detect Sensor:
 -  Japan "KEYENCE”∮0.8 mm Optoelectronic Fiber Sensor
＊ Optoelectronic Fiber Sensor: Included Focusing Lenses
＊ Product Detect Sensor:
 -  Japan “KEYENCE” Optoelectronic Fiber Sensor

* The brand names of products shown in the catalogue are the reference application to our manufacturing equipment only.

Order Information:

• Minimum Order: Negotiable
• Branded Product
