Automatic Labeling Machine with Automatic Feeding & Collecting for Plastic Thermoforming Egg Carton/Box/Tray/Clamshell(Plastic Thermoforming Egg Carton/Box/Tray/Clamshell Labeling Series 321-VA-EGAA-S3 (152)) - Unimax Group Engineering & Development Corporation.

New Product Announce!

Home> Products>Thermoforming Egg Carton/Box/Tray Lid Labeling & Marking Sector [Packaging Department]

Product

Automatic Labeling Machine with Automatic Feeding & Collecting for Plastic Thermoforming Egg Carton/Box/Tray/Clamshell

Plastic/PET Thermoforming Egg Carton Labeling Machine

Product ID: Plastic Thermoforming Egg Carton/Box/Tray/Clamshell Labeling Series 321-VA-EGAA-S3 (152)

￭ Model: 321-VA-EGAA-S3
♦ Pressure Sensitive Self-adhesive Type of Label
♦ Twin-Head Labeling System
♦ For Plastic Vacuum Formed/Thermoformed Egg Box/Carton/Tray
♦ Egg Carton Automatic Feeding Continuously
♦ No Need to Stop the Machine For Supplementary Egg Carton Filling
♦ Continuous Automatic Collecting System

￭ Product Example:
- 6-Cell Egg Carton/Box/Tray
- 10-Cell Egg Carton/Box/Tray
- 12-Cell Egg Carton/Box/Tray
- 15-Cell Egg Carton/Box/Tray
- 2 * 6-Cell Egg Carton/Box/Tray
- 30-Cell Egg Tray Lid
- Clamshell
- Food Box
- Fruit Box

Specifications:

￭ Specification:
• Labeling Speed: Approx. 40 Pieces/Min.
• Labeling Product: Lay-Flat 145 ~ 150 (L) * 220 (W) mm.
• Main Label: Max. 200 (L )* 160 (H) Included Base Paper.
• Strip Label: Max. 200 (L) * 13 (H) Included Base Paper.
• Label Roll: ø 300 (O.D.) * 76 (I.D.) mm.
• Machine Size: Approx. 5000 (L) * 900 (W) * 1450 (H) mm.

Features:

￭ Features:
• Japan "MITSUBISH" PLC Control System.
• Japan "YASKAWA" Servo Motor Control System.
• Interfaced 10" Colorful HMI Touch Screen Monitor.
• Label Sensor: "SICK" Optoelectronic Sensor.
• Product Detect Sensor: "OMRON" Optoelectronic Sensor.

* The brand names of products shown in the catalogue are the reference application to our manufacturing equipment only.

Order Information:

Minimum Order: Negotiable
