Mini Wrapping Machine UTK-2002A/B/C Multi-Purpose Series

Multi-Application Mini Wrapping Machine

Product ID: Packing Machine Sector Mini-Wrapping UTK-2002A/B/C Series

Model No. : UTK-2002A/B/C
All commodities with adequate size can adopted by this multi-purpose series of machine, except those can not stand for hot-sealing, whatever candies, chocolate bar, chewing gums, biscuits, medicine, soaps, ice-bar, ice-pop, facial paper, wet wipes, dry cell, cutlery, panned goods; whatever its shape is square, rectangle, bar, or round, etc.

Specifications:

￭ Models: Multi-purpose Mini Wrapping Series:
• A: Automatic feeding conveyor for manual feeding.
• B-1: Automatic rotary feeding disc center feeding.
• B-2: Automatic rotary feeding disc side feeding.
• B-3: Automatic rotary big disc center feeding.
• C: With stainless tray for manual feeding on conveyor.
• D: With cut-off and automatic feeding.
• E: With stack hopper mechanic feeding.
• If required a quotation, please specify detailed requirement.

Features:

￭ Features:

♦ The tailor-make type of machines with special specification
or additional attachments to be optional.

See more complete detail

￭ Reference Main Specification:

MODEL	UTK-2002A	UTK-2002B	UTK-2002C
MOTOR	1/2 HP	1/2 HP	1/2 HP
HEATER	110 V, 2.5 KW	110 V, 2.5 KW	110 V, 2.5 KW
PACKING SIZE (MM)	(L)(W)(H) MM MAX.2805025 MIN. 22136	(L)(W)(H) MM MAX. 361816 MIN. 22136	(L)(W)(H) MM MAX. 2805025 MIN. 22136
PACKING VARIETY	TRIPE SIDES SEALING (FLAT, THREAD, SAW-TEETH / INDENTED SHAPES)
PACKING SPEED	16,500 MM/MIN	16,500 MM/MIN	16,500 MM/MIN
MACHINE DIMENSION	(L)(W)(H)MM 29008501360	(L)(W)(H)MM 180012001360	(L)(W)(H) MM 21509001450
MACHINE WEIGHT	APPROX. 600KGS	APPROX. 750 KGS	APPROX. 6 50 KGS
