Specifications:

￭ Main Specification:
• 620E-V4H Labeling Speed: Approx. 80~90 PCS/MIN.
• 620E-V6H Labeling Speed: Approx. 100 PCS/MIN.
• Servo Control Conveyor: 3500 *200 * 900 MM / 6400 * 200 * 860 MM
• 620E-V4H / 620E-V6H : Equipped with Mold-Sets *33 / 65 Sets
• Equipped with Automatic Position Setting System
• Equipped with Enhanced Double-Side Labeling System
• Label Size: Max. 120 (L) * 20 (H) MM

• 620E-V6H
- Equipped with NG Product Taking-Collecting System
- Equipped with CCD Detect & Monitoring System
- Equipped with Aluminum Safety Protection Door & Frame

• Machine Dimension:
- Approx. 3,500 * 1,500 * 1,650 MM / 6,800 *1,500 *1,780 MM

Features:

♦ Features & Advantages:
• Servo Motor Control Labeling System with Servo Control Conveyor
• Labeling Height and Forward/Backward Position Adjustable

♦ Main machine structure:
   Aluminum alloy and stainless steel with anodizing treatment
• Programmable logic control (PLC) system with mini micro encoder.
• HMI Touch Screen Monitor operation control system.
• With high precision sensor detect and activating system.
• With servo motor control labeling system.

* The brand names of products shown in the catalogue are the reference application to our manufacturing equipment only.

Order Information:

• Minimum Order: Negotiable
• Branded Product
