Product
Thermoforming Product Automatic Labeling Machine with Automatic Stacking & Collecting System

Product ID: Plastic Vacuum / Thermoforming Product Labeling Series 310-VA-S2 / 320-VA-S3 (125)
♦ Application:
• Off-Line Labeling Application
• For Plastic Therforming /Vacuum Formed Cut-Trimmed Product:
PET Clamshell / Container / Box / Tray
• Automatic Peel-off Taking System
• Automatic Stacking Batch Collecting System
• Single Line Product Transportation System
♦ Model:
• 311-VA-S2 Automatic Single-Labeling System
• 321-VA-S3 Automatic Twin-Labeling System
* High Precision Servo Motor Control Labeling System.
Specifications:
♦ Control System:
• Japan "Mitsubishi" PLC Control Sytem
• Inter-faced Colorful Touch Screen Monitor
• Conveyor with Japan Orient AC Motor Driving System
• With Italy Warm Gear Speed Reducer
• With Japan "YASKAWA" Servo Motor Labeling System
• Label Detecting Sensor: "Sick" Brand
♦ Specification:
• Product Size (Opened):
- Max. 330 (L) x 350/450 (W) mm (Formed & Trimmed)
• Labeling Accuracy: ± 2 mm
• Collector: 300 mm in Height
• Conveyor Feeding Speed: Approx. 30 m/min
• Operation Speed: Approx. 6~18 m/min
• Reference Capacity:
- Approx. 30~40 pcs/min Depend on Substances and Specification
• Product Size (Opened):
- Max. 330 (L) x 350/450 (W) mm (Formed & Trimmed)
♦ Optional:
• Transparent Label Sensor System
• Non Air Bubble Labeling Mechanism
- For More Rigid Substances and Transparent Label
Features:
♦ Features:
• For Products Top Labeling by Self-Adhesive Label
• Computerized Labeing Mechanism
• No Scrash on Label & substances
• Servo Motor Control Pressure Sensitive Labeling System
• Nontransparent Type of Label
- Easy to Change Labeling and Conveyor Speed
• Easy to Adjust and Control Conveyor with Labeling Synchronously
• Labeling and Counting Synchronously
• Easy to Re-Load Label Roll while Running Out the Labels
• Short Time Needed only for Replacing Label Roll
• Automatic Clamshell / Box / Tray Take-Off with Stacking Collector - Servo Montro Contol system Receiver
• Adjustable Control for Labeling System
- Labeling Position/ Height / Angle
* The brand names of products shown in the catalogue are the reference application to our manufacturing equipment only.
Order Information:
- Minimum Order: Negotiable
- Branded Product
